PHOTOELECTRIC SMOKE DETECTOR
Features:
- Low profile design
- Low current draw
- Backward compatible with Series 100 detector range of bases
- Wide operating voltage 8 to 30VDC
- Bi-colour LED detector status indicator
- Automatic drift compensation
- Programmable sensitivity
- Addressable feature
- Advanced maintenance features via remote hand-held test unit
- Range of detector bases available
Technical Specifications:
- Operating Voltage Range: 8 to 30VDC (Nominal 12/24VDC)
- Typical Standby Current: 50μA @ 24VDC (LED no blink)
- Maximum Permissible Alarm Current (LED On): 80mA @ 24VDC (Limited by panel)
- Operating Temperature Range: -30˚C to +70˚C
- Humidity: 5 to 95% Relative Humidity (non condensing)
- Height: 38mm (plus 9mm for B401 base)
- Diameter: 102mm
- Weight: 105g (plus 60g for B401 base)
